Configuration :- Grit rolling type
Drive method :- Digital servo drive
Max. cutting area (W x L) (*1) :- 603mm × 50m
Cutting area of guaranteed accuracy (*1) :- 583mm × 2m
(When using optional basket) :- (583mm × 5m)
Mountable :- Min :- 50mm
media width :- Max :- 712mm (28inch)
Mountable roll media mass :- 9kg
Number of push rollers :- 2 rollers
Max. cutting speed :-900mm/s at 45° direction
Acceleration :- Max. 21.2m/s2 at 45° direction
Cutting force :- Max. 4.41N (450gf)
Minimum character size :- Approx. 5 mm alphanumeric (varies depending on character font and media)
Mechanical resolution :- 0.005mm
Programmable resolution :- GP-GL：0.1/0.05/0.025/0.01mm　HP-GLTM (*2)：0.025mm
Repeatability (*1) :- Max. 0.1 mm in plot up to 2 m (Excluding media expansion and contraction)
Mountable number of tools :- 1 tool
Blade types :- Super steel
Pen types :- Oil-based ballpoint pen, Water-based fiber-tip pen
Media types :- Up to 0.25mm thickness, Marking film (PVC / fluorescence / reflection), polyester film (With specified conditions)
Interface :- USB 2.0(Full Speed), Ethernet 10BASE-T/100BASE-TX
Buffer memory :- 2MB
Command sets :- GP-GL / HP-GL™ (Set by command or auto-detect) (*2)
Display :- Graphic type LCD with back-light (240dots x 128dots), supports 10 languages
Power source:- 100V to 120V AC, 200V to 240V AC, 50 / 60 Hz
Power consumption :- Up to 100W
Operating environment :- 10 to 35 ºC, 35 to 75 % R.H. (non-condensing)
Guaranteed accuracy environmentN:- 16 to 32 ºC, 35 to 70 % R.H. (non-condensing)
External dimensions (W x D x H) :- Approx. 1005 × 582 × 1092 mm
(with basket) :- (1005 × 936 × 1092 mm)(*3)
Weight (approx.) :- 23 kg
(with basket) :- (25.2 kg)(*3)
Compatible OS (*4) :- Windows 11/10/8.1 macOS 10.13 (High Sierra) to 13 (Ventura)
Supported software (*5) :- Graphtec Pro Studio(Windows)(*6), Graphtec Studio(Mac), Cutting Master 4(*6), Windows Driver
Safety :- PSE,UL/cUL,CE mark
EMC :- VCCI Class A,FCC Class A,CE mark
